Metallic Bonds

What is a Metallic Bond?

Metallic bond is a term used to describe the collective sharing of a sea of valence electrons between several positively charged metal ions. Metallic bonding is a type of chemical bonding and is responsible for several characteristic properties of metals such as their shiny luster, their malleability, and their conductivities for heat and electricity.

Both metallic and covalent bonding can be observed in some metal samples. For example, covalently bonded gallium atoms tend to form crystal structures that are held together via metallic bonds. The mercurous ion also exhibits metallic and covalent bonding.

The factors that affect the strength of a metallic bond include:

  • Total number of delocalized electrons.
  • Magnitude of positive charge held by the metal cation.
  • Ionic radius of the cation

An illustration describing the way electrons are delocalized over a rigid lattice of metal ions in a metallic bond is provided below.

Metallic Bond

Metallic bonds are not broken when the metal is heated into the melt state. Instead, these bonds are weakened, causing the ordered array of metal ions to lose their definite, rigid structure and become liquid. However, these bonds are completely broken when the metal is heated to its boiling point.

Example – Metallic Bonding in Sodium

The electron configuration of sodium is 1s22s22p63s1; it contains one electron in its valence shell. In the solid state, metallic sodium features an array of Na+ ions that are surrounded by a sea of 3s electrons. However, it would be incorrect to think of metallic sodium as an ion since the sea of electrons is shared by all the sodium cations, quenching the positive charge.

An illustration describing the metallic bonding in sodium is provided below.

Metallic Bond in Sodium

The softness and low melting point of sodium can be explained by the relatively low number of electrons in the electron sea and the relatively small charge on the sodium cation. For example, metallic magnesium consists of an array of Mg2+ ions. The electron sea here contains twice the number of electrons than the one in sodium (since two 3s electrons are delocalized into the sea). Due to the greater magnitude of charge and the greater electron density in the sea, the melting point of magnesium (~650oC) is significantly higher than that of sodium.

Properties Attributed by Metallic Bonding

Metallic bonds impart several important properties to metals that make them commercially desirable. Some of these properties are briefly described in this subsection.

Electrical Conductivity

Electrical conductivity is a measure of the ability of a substance to allow a charge to move through it. Since the movement of electrons is not restricted in the electron sea, any electric current passed through the metal passes through it, as illustrated below.

Electrical Conductivity due to Metallic Bonds

When a potential difference is introduced to the metal, the delocalized electrons start moving towards the positive charge. This is the reason why metals are generally good conductors of electric current.

Thermal Conductivity

The thermal conductivity of a material is a measure of its ability to conduct/transfer heat. When one end of a metallic substance is heated, the kinetic energy of the electrons in that area increases. These electrons transfer their kinetic energies to other electrons in the sea via collisions.

The greater the mobility of the electrons, the quicker the transfer of kinetic energy. Due to metallic bonds, the delocalized electrons are highly mobile and they transfer the heat through the metallic substance by colliding with other electrons.

Malleability and Ductility

When an ionic crystal (such a sodium chloride crystal) is beaten with a hammer, it shatters into many smaller pieces. This is because the atoms in the crystals are held together in a rigid lattice that is not easily deformed. The introduction of a force (from the hammer) causes the crystal structure to fracture, resulting in the shattering of the crystal.

In the case of metals, the sea of electrons in the metallic bond enables the deformation of the lattice. Therefore, when metals are beaten with a hammer, the rigid lattice is deformed and not fractured. This is why metals can be beaten into thin sheets. Since these lattices do not fracture easily, metals are said to be highly ductile.

Metallic Luster

When light is incident on a metallic surface, the energy of the photon is absorbed by the sea of electrons that constitute the metallic bond. The absorption of energy excites the electrons, increasing their energy levels. These excited electrons quickly return to their ground states, emitting light in the process. This emission of light due to the de-excitation of electrons attributes a shiny metallic luster to the metal.

High Melting and Boiling Points

As a result of powerful metallic bonding, the attractive force between the metal atoms is quite strong. In order to overcome this force of attraction, a great deal of energy is required. This is the reason why metals tend to have high melting and boiling points. The exceptions to this include zinc, cadmium, and mercury (explained by their electron configurations, which end with ns2).

The metallic bond can retain its strength even when the metal is in its melt state. For example, gallium melts at 29.76oC but boils only at 2400oC. Therefore, molten gallium is a nonvolatile liquid.

Frequently Asked Questions

What is the Difference Between Metallic Bonding and Ionic Bonding?

Ionic bonds involve the transfer of electrons between two chemical species. They arise from a difference in the electronegativities of the bonded atoms. On the other hand, metallic bonds are formed when a rigid, definite lattice of metal cations share a sea of delocalized valence electrons. However, both these types of bonding involve electrostatic forces of attraction.

What are the Factors Affecting the Strength of Metallic Bonds?

The three factors are:

  1. The number of electrons delocalized from the metal; the greater the number of delocalized electrons, the stronger the bond
  2. Charge held by the metal cation; the greater the magnitude of the charge, the stronger the force of attraction between the electron sea and the cations.
  3. Size of the cation; the smaller the ionic radius, the greater the effective nuclear charge acting on the electron sea.

Thus, the electron configuration of the element can be studied to predict the strength of the metallic bonding in it.

Which Properties of Metals can be Explained by Metallic Bonding?

The properties of metals that are a consequence of metallic bonding include:

  • Malleability
  • Ductility
  • High melting and boiling point.
  • High electrical and thermal conductivity.
  • Metallic luster.
